Teltonika FMB140 — tracker and CAN reader in one unit
The FMB140 locates the vehicle and reads its data bus at the same time, so fuel level, consumption, mileage and engine RPM come from the vehicle itself rather than from an estimate — with no separate CAN adapter to fit. Specifications below are the manufacturer's.
- 2 CAN
- Vehicle bus interfaces read by the unit itself
- < 3 m
- GNSS positioning accuracy
- 10 – 30 V
- Supply range, with a 170 mAh backup battery
- 55 g
- 65 × 56.6 × 20.6 mm housing, IP41
CAN data
What it reads off the vehicle
With the LV-CAN200 software option the unit ships with, these parameters come straight from the vehicle's own bus.
- Fuel level as the dashboard reads it
- Total fuel consumption
- Vehicle speed from the wheels
- Vehicle driven distance
- Engine speed (RPM)
- Accelerator pedal position
Two software options
LV-CAN200 is the option the device ships with and covers light vehicles, trucks and buses. Teltonika's ALL-CAN300 option extends the parameter set for agriculture and special transport.
Which parameters a given vehicle actually exposes depends on the vehicle. We check the make, model and year against Teltonika's supported-vehicle list before we quote, rather than promising a parameter the bus does not carry.
Ask us about your vehiclesSpecifications
FMB140 capability in detail
Teltonika's published specification for the unit KASSA supplies and installs.
GNSS
- GPS, GLONASS, GALILEO, BEIDOU, QZSS and AGPS
- 33 tracking channels
- Tracking sensitivity −165 dBm
- Accuracy < 3 m
- Hot start < 1 s, warm start < 25 s, cold start < 35 s
- Internal high-gain GNSS antenna
Cellular
- GSM quad-band 850 / 900 / 1800 / 1900 MHz
- GPRS Multi-Slot Class 12, up to 240 kbps
- GPRS Mobile Station Class B
- SMS in text and data
- Micro-SIM and eSIM
- Internal high-gain GSM antenna
CAN and interfaces
- 2 CAN interfaces read by the unit itself — no separate CAN adapter
- 3 digital inputs, one of them negative, two impulse-capable
- 2 digital outputs and 2 analog inputs
- 1-Wire for iButton driver identification and temperature sensors
- USB 2.0 micro-USB for configuration
- 3 status LEDs
Power and memory
- Supply 10 – 30 V DC with overvoltage protection
- 170 mAh Li-ion backup battery, 3.7 V (0.63 Wh)
- 128 MB internal flash memory for offline buffering
- Ignition detected from DIN1, the accelerometer, supply voltage or engine RPM
- GPS sleep, online deep sleep, deep sleep and ultra deep sleep modes
Bluetooth
- Bluetooth 4.0 + LE
- Temperature and humidity sensors
- Universal BLE sensor support
- OBDII dongle, headset and Inateck barcode scanner
- Configuration over Bluetooth from the FMBT mobile application
Physical and environment
- 65 × 56.6 × 20.6 mm, 55 g
- IP41 ingress protection
- Operating temperature −40 °C to +85 °C without the battery
- Operating humidity 5% to 95%, non-condensing
- Battery charge 0 °C to +45 °C, discharge −20 °C to +60 °C
On-device logic
Events the unit detects by itself
Scenarios configured on the device, so an event is recorded and stored even where mobile coverage drops — the 128 MB of internal memory buffers until the unit is back on the network.
- Green Driving
- Over-speeding detection
- Excessive idling detection
- Crash detection
- Towing detection
- Unplug detection
- Jamming detection
- Immobilizer
- iButton read notification
- GNSS fuel counter
- Auto and manual geofence
- Trip
Configuration and firmware reach the unit over FOTA Web, the Teltonika Configurator by USB or Bluetooth, or the FMBT mobile application — so a change to a vehicle's setup does not require the vehicle to come back to the workshop.
Selecting a device
Applications, compatibility and where it fits
Which vehicles the unit suits, what it works with, and the solutions it feeds once it is installed.
Applications
- Teltonika FMB140
- Fleets that need engine and vehicle data alongside position — light and electric vehicles, trucks, buses and special machinery.
Compatibility
- Reports into the KASSA fleet management platform
- Fleet data available through the KASSA API
- Accepts fuel level sensors, driver ID and vehicle sensors
Related solutions
Teltonika FMB140
Is the FMB140 the right unit for your fleet?
Tell us your vehicle makes, models and what you need to measure, and we will confirm what the bus exposes and quote the unit, sensors and installation.
